Grandstream GDS3710 IP Video Intercom System, Motion Detection, 1080P Resolution, 180-Degree Wall-to-Wall Coverage


The Grandstream GDS3710 is a high-definition IP Video Door System that combines access control, intercom functionality, and surveillance capabilities into a single, robust device. Designed for secure facility access and monitoring, it is suitable for various environments, including office buildings, residential complexes, and commercial properties.

د.ك79.00

Compare

The Grandstream GDS3710 is a high-definition IP Video Door System that combines access control, intercom functionality, and surveillance capabilities into a single, robust device. Designed for secure facility access and monitoring, it is suitable for various environments, including office buildings, residential complexes, and commercial properties.

  • High-Definition Video: Equipped with a 2-megapixel CMOS sensor, the GDS3710 delivers 1080p Full HD video at 30 frames per second, ensuring clear and detailed imaging.
  • Wide-Angle Coverage: The built-in hemispheric camera offers a 180° horizontal and 150° vertical field of view, providing comprehensive wall-to-wall coverage without blind spots.
  • Keyless Entry: Features an integrated RFID chip reader, allowing for secure, keyless access using RFID cards or fobs.
  • Two-Way Audio Communication: Includes a built-in microphone and HD loudspeaker, facilitating clear two-way audio communication for intercom functionality.
  • SIP/VoIP Integration: Supports SIP/VoIP protocols, enabling video streaming and two-way audio to IP phones, video intercom stations, smartphones, and NVRs simultaneously.
  • Durable Construction: Constructed with a metal casing that is both weatherproof (IP66 certified) and vandal-resistant (IK10 certified), ensuring reliable operation in various environmental conditions.
  • Motion Detection and Alarm Integration: Supports motion detection and includes alarm-in and alarm-out interfaces for integration with existing security systems.
  • Power over Ethernet (PoE): Supports PoE (IEEE 802.3af), simplifying installation by providing both power and network connectivity through a single cable.
  • ONVIF Compliance: Compliant with ONVIF Profile S, allowing for seamless integration with third-party ONVIF-compliant surveillance and recording solutions.
  • Management Software: Compatible with Grandstream’s free GDS Manager software, enabling centralized management of RFID card information, video feeds, and device configurations.
SKU: GDS3710 Categories: , Tags: , , Brand:
Brand Grandstream
Video & Camera

Sensor: 1/2.7″ 2MP CMOS (1920 x 1080)

Lens: F2.5, 180° horizontal x 150° vertical field of view

Video Compression: H.264 (High/Main/Base Profile), Motion JPEG

Frame Rate: Up to 30 fps

Minimum Illumination: 0.5 Lux

Wide Dynamic Range: Yes, up to 120 dB

Day/Night Mode: White LEDs with smart brightness control

Video Streams:

  • Primary: 1920 x 1080 (Full HD recording)
  • Secondary: 1280 x 720 (SIP/VoIP video calls)
  • Tertiary: 320 x 240 (smartphone applications
Audio & Intercom

Microphone: Built-in digital microphone with Acoustic Echo Cancellation (AEC), effective up to 1.5 meters

Speaker: Built-in HD loudspeaker (2W), suitable for up to 3 meters

Voice Codecs: G.711µ/a-law, G.722; supports DTMF (RFC2833, SIP INFO)

Communication: Full-duplex two-way audio

Access Control & Security

RFID Reader: 125KHz EM4100; supports up to 2,000 RFID cards (1 card and 1 key fob included)

Keypad: 12-key touchpad plus a capacitive doorbell button, each with individual LED illumination

Alarm Inputs: 2 channels, Vin < 15V, for door sensors or other devices

Alarm Outputs: 2 channels, 125VAC/0.5A or 30VDC/2A, Normally Open or Normally Closed, for electric locks, light switches, or other devices

Expansion Interfaces: RS485, Wiegand (26-bit) input and output

Motion Detection: Supported, with up to 4 privacy masks

Connectivity & Integration

Network Interface: 10M/100M auto-sensing Ethernet

Power Supply: PoE IEEE 802.3af Class 3 or 12VDC/1A (AC adapter not included)

Protocols: TCP/IP, UDP, RTP/RTCP, HTTP/HTTPS, ARP/RARP, ICMP, LLDP-MED, DNS, DHCP, SSH, SMTP, TFTP, NTP, STUN, TLS, SRTP

SIP/VoIP Support: Broad interoperability with most third-party SIP/VoIP devices and leading SIP/NGN/IMS platforms

Security: User and administrator level access control, MD5 and MD5-sess based authentication, 256-bit AES encrypted configuration file, TLS, SRTP, HTTPS, 802.1x media access control

Provisioning: Firmware upgrade via TFTP/HTTP/HTTPS; mass provisioning using TR-069 (pending) or AES encrypted XML configuration file

Interoperability: ONVIF Profile S compliant

Build & Durability

Casing: Metal construction, weatherproof (IP66) and vandal-resistant (IK09)

Operating Temperature: -30°C to 60°C (-22°F to 140°F)

Storage Temperature: -35°C to 60°C (-31°F to 140°F)

Humidity: 10% to 90% non-condensing

Dimensions: 173mm (H) x 80mm (W) x 36mm (D)

Weight: Approximately 0.6 kg

Package Contents

GDS3710 Intercom Unit

Installation Bracket

Frame Back Cover

Wiegand Cable

Drilling Template

Bracket Screws and Anchors

Rubber Gaskets

Back Panel Screws

Anti-Tamper Screws and Hex Key

RFID Cards and Key Fobs

Quick Installation Guide
